Keep the log and large-scale debris away with Log Screen Boom.
Log screen boom is a barrier with float units and mesh screen underneath to contain logs and large -scale debris in marinas. The mesh screens are jointed with full articulation between units to provide a seamless barrier.
Technical Specifications |
LSB600 | LSB800 | LSB1000 |
|---|---|---|---|
| Float Size | Ø600 mm x 900 mm | Ø800 mm x 1,240 mm | Ø1,000 mm x 1,240 mm |
| Core Tube Size | Ø88.9 mm x 5 mm | Ø114 mm x 5 mm | Ø114 mm x 5 mm |
| Mesh Screen | 17 mm x 45 mm | 17 mm x 45 mm | 17 mm x 45 mm |
| Max. Break Load | 100 tonnes | 100 tonnes | 100 tonnes |
| Datasheet | Datasheet | Datasheet |
Our partnerships include companies specializing in marine barriers for environmental, safety, and security purposes. Together, we are committed to setting new standards in the railway and marine industries, driving progress, and delivering exceptional value to our customers.
ADOR Tech have successfully delivered and installed log screen booms on a smallish dam in BC’s Okanagan as a solution to block floating logs and branches.
Yes. Log screen boom is provided fully customizable to address project’s challenges efficiently.
Log boom system is typically used to prevent logs and large-scale floating debris from passing through.
The screen of log screen boom is designed with hot-dipped galvanized steel, ensuring high-performance.
Log screen barrier is ideal for marinas with medium duration waves and moderate to high tidal flows.
Yes. Log boom system is engineered highly durable with UV-stabilized Polyethylene float units, ensuring maximum efficiency in different weather conditions.
Yes. Log boom systems are provided fully customizable and can be designed with HDPE float units.
Log screen boom is a heavy-duty barrier used to prevent large, heavy floating debris and trash, like logs, branches, and ice from passing through. For hydro dams and water channels where floating logs, ice, and large-scale debris can harm their structure, log boom systems offer unmatched strength and coverage with their ultra-high resistance and heavy loads. They can also be used in natural waterways and reservoirs with continuous waves and tidal flows efficiently.
Log boom system includes float units with mesh screen underneath. The float units are made from Polyethylene foam, filled with closed-cell solid Polyethylene foam, covering the surface water level. The underneath screen is designed with hot-dipped galvanized steel diamond mesh in a steel frame that ensures no heavy debris passing from under the float units. The spaces between mesh screens are fully articulated, ensuring maximum debris control.
Log screen boom is provided with fully customizable design to ensure maximum efficiency in Canadian projects, where heavy break load and all-weather operation are the priority. One of the most common challenges in Canada marinas is water level adjustments. Water levels may be changed in some intervals, which disrupts the performance of log boom system installed for long-term operations. The log screen boom can be equipped with water-level compensators at the end connections to adjust the log screen with water level changes.
